- Colour scanning
- Achieve optimum performance with TWAIN, WIA, ICA, SANE drivers
- USB-powered
Information
Overview
Specifications
Basic Specs
Document Size - Single Sheet - Width
Letter: 216 mm
Colour Depth - Input
24-bit colour processing
Colour Depth - Output
24-bit colour processing
Resolution - Optical
Max. 600 dpi × 600 dpi
Memory Capacity
256 MB
Display Type
Touchscreen LCD
3.7 inches, STN colour LCD screen
Operation
Power Source
USB bus-power 5V DC
Power Consumption - Scanning
Approx. 2.3W
Power Consumption - Ready
Approx. 0.7W
Power Consumption - Power Saving / Deep Sleep
Approx. 0.01W
Temperature Operating
5°C to 40°C
Humidity - Operating
20% to 80%
Compliance
TWAIN Compliant - Windows®
Windows® XP / Windows Vista® / Windows® 7
TWAIN Compliant - Macintosh
Mac OS X v10.3, v10.4, v10.5, v10.6, v10.7
WIA Compliant - Windows®
Windows® XP / Windows Vista® / Windows® 7
